Modular facade system of the new generation
PanelKIT — is a patented facade system based on the principle of panel set: an assembled structural frame that can be insulated, finished, and installed without the need for one's own high-tech manufacturing. The system is oriented towards decentralized production, scalability, and integration with any architectural environment.
1 - Thermal profile vertical
2 - Thermal profile groove
horizontal
3.7 - Frame for windows and doors
4 - Thermal beam corner post
5 - Adjustment bracket
6 - Telescopic bracket
8 - Corner reinforcement bracket
Thermoprofile upright
Slot thermoprofile
horizontal
Thermal beam corner post
Stained glass
Corner shelf
Prepare standard window
Structural System
PanelKIT consists of the following elements:
• Thermal Beams: steel closed profile with thermal cutouts (“blinds”), internal reinforcement and filled with rigid polyurethane foam. They provide load-bearing capacity, thermal and sound insulation, including corner elements that form the external and internal angles of the building facade.
• Thermal Profiles: perforated metal elements with thermal breaks that increase rigidity and reduce thermal conductivity.
• Ready-Made Frames (windows and doors): integrate into the framework without disrupting the thermal insulation contour.
• Installation Connections: corner elements, concealed locks, adjustable brackets HOOK-BRACKET and TELEBRACKET.
Features of the design
• High geometric accuracy and strength of the panels;
• Variability in the placement of windows, doors, and engineering systems;
• Full compatibility with window systems from any manufacturer;
• Possibility of installation in buildings with concrete, steel, or modular frames.
• Equipped with an adapted subsystem of a ventilated façade.
Production Model
PanelKIT uses a two-step approach:
1. Centralized production of thermally insulated elements and precision framework;
2. Local assembly: insulation, finishing, and installation — in the workshop or on the construction site.
Delivery formats
• In assembled form (ready frame);
• In flat packaging (flat pack) — for transportation and assembly on site;
• Individual sizes and placement of embedded parts as per the project.
Application and adaptability
PanelKIT is suitable for:
• Residential, commercial and industrial buildings;
• Modular and fast construction;
• Renovation and energy-efficient modernization;
• Use in remote and hard-to-reach areas.
The system easily adapts to any climatic conditions, architecture, and building standards.
Horizontal joint of panels
Mounting Elements
Installation and connections
• Suspended installation: using an adjustable bracket HOOK-BRACKET (anchored to the top slab);
• Interfloor installation: using a telescopic bracket TELEBRACKET;
• In the CoreFRAME system: using a tongue-and-groove connection, where the grooves are formed in the upper and lower edge of the panel, and the tongue is the load-bearing beam of the building frame.
• Without welding, wet processes, and heavy equipment.
Advantages PanelKIT
1. Industrialization without a factory — production is possible in any region;
2. Flexibility of finishing — any insulators, facing materials, and design solutions;
3. Accelerated timelines — quick installation without complex equipment;
4. Versatility — compatible with various types of load-bearing structures and window units;
5. Cost savings — reduction of logistics costs and labor costs;
6. Sustainability — waste reduction, support for local contractors, inclusion in social programs.
